Multifunction Stabilized Soil and Asphalt Surface Paver RP953 Shangchai Euro II 163KW
Multifunction Stabilized Soil and Asphalt Surface Paver RP953 adopt Shangchai Euro Ⅲ engine 162kw (with economic mode) + mechanically assembled screed (air heating, double vibrating) + Linde hydraulic system + standard version intelligent control system + XCMG leveling instrument/level indicator + centralized lubrication
Stabilized soil and asphalt surface paving, mainly suitable for high-grade road construction; meets 500mm super thick paving
The basic paving width is 2.5m, and the maximum paving width is 10.5m. The maximum paving thickness is 500mm, with ECO economic working mode.
RP953 Road Paver Specifications:
| Item | Unit | Specs |
| M250A |
| Basic paving width | m | 2.5 |
| Maximum paving width | m | 10.5 |
| Maximum paving thickness | mm | 500 |
| Working speed | m/min | 18 |
| Maximum travel speed | km/h | 3.0 |
| Theoretical productivity | t/h | 900 |
| Hopper capacity | t | 15 |
| Gradeability | ％ | ≥20 |
| Flatness (standard deviation) | mm | 1.2 |
| Cross slope error | % | ±0.2 |
| Crown adjustment range | % | -1～+4 |
| Diesel engine model | / | SC9DK220 |
| Diesel engine power | kW | 162 |
| Diesel engine speed | r/min | 2000 |
| Splitting speed | r/min | 0～90 |
| Conveying speed | m/min | 0～27 |
| Vibration speed | r/min | 0～1500 |
| Vibration amplitude | mm | Main: 5 Sub: 0,3,6,9,12 |
| Dimensions | mm | 6900×2780×4060 |
| Total Weight | t | 22～31.5 |
| Diesel tank volume | L | 300 |
| Hydraulic oil tank volume | L | 300 |
| Screed heating method | / | Gas heating |
| Conveying material level control method | / | Angle sensor automatic control |
| Sub-material level control method | / | Ultrasonic sensor automatic control |
| Automatic leveling control mode | / | Analog leveling instrument |
Features:
(1) RP953 Road Paver adopts the mature and reliable SC9DK220 diesel engine of Shangchai, with strong power up to 162kW.
(2) RP953 Road Paver adopts three-in-one powerful composite radiator, and through forced centralized heat removal, it can ensure that the whole machine can work continuously for a long time at a high temperature of 50℃.
(3) Independent driving left and right, microcomputer control, and constant speed automatic control technology for paving speed.
(4) Four sets of independent hydraulic drive systems are used for conveying and distributing materials, and the material level adopts ultrasonic sensor control technology to ensure a constant material level.
(5) The distribution device can be moved up and down to adapt to different paving thicknesses, reducing material segregation and power consumption.
(6) The distributing blade adopts high wear-resistant alloy material, and the conveying soleplate and screed soleplate adopt high wear-resistant steel plate, which effectively prolongs the service life of the machine.
(7) The mechanically lengthened double vibrating air heating screed has good rigidity and high working density.
(8) Two vertical and one horizontal automatic leveling systems ensure the smoothness of the working road surface.
(9) The console can intuitively display various working functions, paving and driving speeds, and can move left and right for easy operation.
(10) The centralized lubrication system can automatically supply lubrication to the bearings of various high-temperature parts.
(11) RP953 Road Paver has high degree of automation, simple and convenient operation, good construction quality and high work efficiency.
